Listing photo. Request current-lot confirmation.
IC FPGA 2000 LOGIC ELEMENTS 153MBGA
Key Specifications
| Complete manufacturer part number | 10M02SCM153C8G |
|---|---|
| Manufacturer | Altera (Intel) |
| Description | IC FPGA 2000 LOGIC ELEMENTS 153MBGA |
| Package / case | 153-MBGA (8x8mm) |
| Product category | Programmable logic |
| Series / Family | MAX 10 |
| Power supply | Power Supply (VCC_ONE) 3.0 V or 3.3 V; internally regulated to ~1.2 V core |
| Logic elements | 2,000 |
| Pins | 153 |
| Mounting Type | Surface Mount |
| Embedded Memory | 108 Kb |
| 18x18 Multipliers | — |
| User I/O | 112 |
| Speed Grade | -8 |
| Operating temperature (catalog record) | 0°C to +85°C |
| Package code | M153 |
| External memory interfaces (device/package catalog) | SRAM |
| PLLs (device/package catalog) | 2 |
| Maximum LVDS (device/package catalog) | 9 |
| Security features (device/package catalog) | AES-128 Encryption, Unique Chip ID, JTAG secure mode, Verify Protect |
| In stock | 11,529 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
Available manufacturer parameters matched to the complete ordering code. Historical captures may be used. Parameter verification does not certify product photography or current stock; consult the linked datasheet for conditions.
Some exact-order specifications remain to be confirmed in the manufacturer documentation.
Request a Quote
Part of the MAX 10 series.
