Listing photo. Request current-lot confirmation.
8-Channel, 1 MSPS, Ultralow Power, 12-Bit ADC in 24-Lead TSSOP
Key Specifications
| Complete manufacturer part number | AD7091R-8BCPZ-RL7 |
|---|---|
| Manufacturer | Analog Devices |
| Description | 8-Channel, 1 MSPS, Ultralow Power, 12-Bit ADC in 24-Lead TSSOP |
| Package / case | 24-Lead LFCSP (4mm x 4mm w/ EP) |
| Product category | Analog-to-digital converters |
| Pins | 24 |
| Number of Bits | 12 |
| Sampling Rate | 1M |
| Number of Inputs | 8 |
| Input Type | Single Ended |
| Data Interface | SPI, DSP |
| Architecture | SAR |
| Voltage - Supply, Analog | 2.09V ~ 5.25V |
| Voltage - Supply, Digital | 2.09V ~ 5.25V |
| Operating temperature (manufacturer ordering record) | -40 °C to 125 °C |
| In stock | 10,201 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
