Listing photo. Request current-lot confirmation.
8-Channel, I2C, 12-Bit SAR ADC with Temperature Sensor
Key Specifications
| Complete manufacturer part number | AD7291BCPZ-RL7 |
|---|---|
| Manufacturer | Analog Devices |
| Description | 8-Channel, I2C, 12-Bit SAR ADC with Temperature Sensor |
| Package / case | 20-Lead LFCSP (4mm x 4mm w/ EP) |
| Product category | Analog-to-digital converters |
| Series / Family | AD7291 |
| Power supply | 2.8 V to 3.6 V |
| Pins | 20 |
| Mounting Type | Surface Mount |
| Resolution | 12-bit |
| Channels | 8 |
| Sampling Rate | 22.2 ksps |
| Interface | I2C |
| Input | Single-ended |
| On-chip | Temperature sensor |
| Operating temperature (manufacturer ordering record) | -40 °C to 125 °C |
| In stock | 2,630 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Request a Quote
Part of the ADI Precision ADC series.
