Manufacturer package outline drawing - not a product photo
3V/5V, 1 mW, 2-Channel Differential, 16-Bit Sigma-Delta ADC
Key Specifications
| Complete manufacturer part number | AD7705BRZ-REEL |
|---|---|
| Manufacturer | Analog Devices |
| Description | 3V/5V, 1 mW, 2-Channel Differential, 16-Bit Sigma-Delta ADC |
| Package / case | 16-Lead SOIC Wide |
| Product category | Analog-to-digital converters |
| Series / Family | AD7705 |
| Power supply | 2.7 V–3.3 V or 4.75 V–5.25 V |
| Pins | 16 |
| Mounting Type | Surface Mount |
| Resolution | 16-bit |
| Channels | 2 differential |
| Sampling Rate | 500 SPS (max update rate) |
| Programmable Gain | 1 to 128 |
| Interface | SPI / QSPI / MICROWIRE / DSP |
| Supply Voltage | 2.7 V–3.3 V or 4.75 V–5.25 V |
| Power | 1 mW max @ 3 V |
| Operating temperature (manufacturer ordering record) | -40 °C to 85 °C |
| In stock | 2,115 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Manufacturer package outline drawing - not a product photo for 16-Lead SOIC Wide. Confirm electrical pin functions in the datasheet. Actual lot appearance and top marking require current-lot confirmation.
Request a Quote
Part of the ADI Precision ADC series.
