The Analog Devices AD7793BRUZ is a low-power, low-noise 24-bit sigma-delta analog-to-digital converter with three differential inputs, an on-chip low-noise programmable-gain instrumentation amplifier and a precision band-gap reference, housed in a 16-lead TSSOP package. It operates from 2.7 V to 5.25 V and provides programmable output data rates from 4.17 Hz to 470 Hz. The device is intended for high-precision measurement of low-bandwidth signals in weighing, temperature and process-control systems.
Key Specifications
| Manufacturer | Analog Devices |
| Manufacturer Part Number | AD7793BRUZ |
| Product Category | Analog to Digital Converters – ADC |
| Package / Case | 16-TSSOP |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C to +105°C |
| Supply Voltage | 2.7 V to 5.25 V |
| Resolution | 24-bit |
| Input Channels | 3 differential |
| Data Rate | 4.17 Hz to 470 Hz |
| Interface | 3-wire / 4-wire SPI |
| Current Consumption | 400 uA typical |
| On-chip | Instrumentation amplifier and band-gap reference |
| Lifecycle Status | Restricted Availability |
| Official Documentation | View official documentation |
Key Features
- 24-bit sigma-delta ADC
- 3 differential inputs
- On-chip low-noise programmable-gain amplifier
- Precision band-gap reference
- Programmable data rate from 4.17 Hz to 470 Hz
- Low 400 uA current consumption
- Simultaneous 50 Hz / 60 Hz rejection
- SPI-compatible serial interface
Applications
- Weigh scales and load cells
- RTD, thermocouple and thermistor measurement
- Industrial process control
- Portable instrumentation
- Smart transmitters
Sourcing
Availability, lead time, date code and commercial terms are subject to confirmation at the time of quotation.
Quality
CHIPER sources brand-new, unused components and provides quality inspection, shortage and long lead-time sourcing, and one-stop BOM procurement. Every part is verified before shipment.
FAQ
What inputs does the AD7793 support?
The AD7793 provides three differential analog inputs for low-bandwidth precision measurement.
Does the AD7793 include a reference?
Yes, it integrates a precision, low-noise band-gap reference, and it also accepts an external reference.
