Manufacturer package outline drawing - not a product photo
3-Channel, Low Noise, Low Power, 24-Bit, Sigma Delta ADC with On-Chip In-Amp
Key Specifications
| Complete manufacturer part number | AD7799BRUZ-REEL |
|---|---|
| Manufacturer | Analog Devices |
| Description | 3-Channel, Low Noise, Low Power, 24-Bit, Sigma Delta ADC with On-Chip In-Amp |
| Package / case | 16-Lead TSSOP |
| Product category | Analog-to-digital converters |
| Series / Family | AD7799 |
| Power supply | 2.7 V to 5.25 V |
| Pins | 16 |
| Mounting Type | Surface Mount |
| Resolution | 24-bit |
| Channels | 3 differential |
| Update Rate | 4.17 Hz to 470 Hz |
| Gain | 1 to 128 |
| Interface | 3-wire serial (SPI) |
| Reference | External (0.1 V to VDD) |
| RMS Noise | 27 nV @ 4.17 Hz |
| Supply Current | 380 µA typ |
| Operating temperature (manufacturer ordering record) | -40 °C to 105 °C |
| In stock | 12,357 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Manufacturer package outline drawing - not a product photo for 16-Lead TSSOP. Confirm electrical pin functions in the datasheet. Actual lot appearance and top marking require current-lot confirmation.
Request a Quote
Part of the ADI Precision ADC series.
