2.7 V to 5.25 V, Micro Power, 8-Channel, 125 kSPS, 12-Bit ADC in 16-Pin TSSOP
Key Specifications
| Complete manufacturer part number | AD7888ARUZ-REEL7 |
|---|---|
| Manufacturer | Analog Devices |
| Description | 2.7 V to 5.25 V, Micro Power, 8-Channel, 125 kSPS, 12-Bit ADC in 16-Pin TSSOP |
| Package / case | 16-Lead TSSOP |
| Product category | Analog-to-digital converters |
| Series / Family | AD7888 |
| Power supply | 2.7 V to 5.25 V |
| Pins | 16 |
| Mounting Type | Surface Mount |
| Resolution | 12-Bit |
| Channels | 8 (Single-Ended) |
| Sampling Rate | 125 kSPS |
| Interface | SPI/QSPI/MICROWIRE/DSP |
| Reference | On-Chip 2.5 V |
| Input Type | Single-Ended |
| Supply Voltage | 2.7 V to 5.25 V |
| Power | 2 mW (typical) |
| Operating temperature (manufacturer ordering record) | -40 °C to 105 °C |
| In stock | 4,758 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Manufacturer package outline drawing - not a product photo for 16-Lead TSSOP. Confirm electrical pin functions in the datasheet. Actual lot appearance and top marking require current-lot confirmation.
Request a Quote
Part of the ADI Precision ADC series.
