Manufacturer package outline drawing - not a product photo
8-Channel, 200 kSPS, 12-Bit ADC with Sequencer in 20-Lead TSSOP
Key Specifications
| Complete manufacturer part number | AD7927BRUZ-REEL7 |
|---|---|
| Manufacturer | Analog Devices |
| Description | 8-Channel, 200 kSPS, 12-Bit ADC with Sequencer in 20-Lead TSSOP |
| Package / case | 20-Lead TSSOP |
| Product category | Analog-to-digital converters |
| Series / Family | AD7927 |
| Power supply | 2.7 V to 5.25 V (AVDD) |
| Pins | 20 |
| Mounting Type | Surface Mount |
| Resolution | 12-bit |
| Channels | 8 (single-ended) |
| Sampling Rate | 200 kSPS |
| Interface | SPI/QSPI/MICROWIRE/DSP-compatible serial |
| Reference | External (REFIN), 0 V to REFIN or 0 V to 2×REFIN |
| Input Type | Single-ended with channel sequencer |
| Power | 3.6 mW typ at 3 V, 200 kSPS |
| Shutdown Current | 0.5 µA max |
| Operating temperature (manufacturer ordering record) | -40 °C to 85 °C |
| In stock | 9,281 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Manufacturer package outline drawing - not a product photo for 20-Lead TSSOP. Confirm electrical pin functions in the datasheet. Actual lot appearance and top marking require current-lot confirmation.
Request a Quote
Part of the ADI Precision ADC series.
