Dual 14-Bit, 20/40/65 MSPS, 3 V Analog-to-Digital Converter
Key Specifications
| Complete manufacturer part number | AD9248BSTZ-20 |
|---|---|
| Manufacturer | Analog Devices |
| Description | Dual 14-Bit, 20/40/65 MSPS, 3 V Analog-to-Digital Converter |
| Package / case | 64-Lead LQFP (7mm x 7mm) |
| Product category | Analog-to-digital converters |
| Series / Family | AD9248 |
| Power supply | 2.7 V to 3.6 V single supply |
| Pins | 64 |
| Mounting Type | Surface Mount |
| Resolution | 14-bit |
| Channels | 2 (dual) |
| Sampling Rate | 20 MSPS |
| Interface | Parallel CMOS |
| Reference | On-chip |
| Input Type | Differential (500 MHz BW) |
| Input Range | 1 Vp-p to 2 Vp-p |
| Supply Voltage | 2.7 V to 3.6 V |
| Operating temperature (manufacturer ordering record) | -40 °C to 85 °C |
| In stock | 5,886 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Manufacturer package outline drawing - not a product photo for 64-Lead LQFP (7mm x 7mm). Confirm electrical pin functions in the datasheet. Actual lot appearance and top marking require current-lot confirmation.
Request a Quote
Part of the ADI Precision ADC series.
