The Intel Cyclone IV E EP4CE6F17I7N is an entry-level low-power FPGA that integrates 6,272 logic elements with 270 Kb of embedded memory in a 256-pin FBGA package. Running from a 1.2 V core supply at the industrial temperature range and -7 speed grade, it is a compact, cost-effective platform for simple control, interfacing and glue-logic functions in industrial and embedded systems.
Key Specifications
| Manufacturer | Altera (Intel) |
| Manufacturer Part Number | EP4CE6F17I7N |
| Product Category | FPGA – Field Programmable Gate Array |
| Package / Case | 256-FBGA (17 mm x 17 mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C to +100°C |
| Supply Voltage | 1.15 V to 1.25 V (core) |
| Logic Elements | 6,272 |
| Embedded Memory | 270 Kb |
| 18×18 Multipliers | 15 |
| User I/O (F256) | 179 |
| Speed Grade | -7 |
| Lifecycle Status | Active |
| Official Documentation | View official documentation |
Key Features
- 6,272 logic elements
- 270 Kb embedded memory
- 15 embedded 18×18 multipliers
- Low 1.2 V core power
- Industrial temperature range
- Compact 256-FBGA package
- Mature, long-life platform
- Quartus Prime software support
Applications
- Industrial control
- Interface and glue logic
- Sensor interfacing
- Simple embedded processing
- Cost-sensitive designs
Sourcing
Availability, lead time, date code and commercial terms are subject to confirmation at the time of quotation.
Quality
CHIPER sources brand-new, unused components and provides quality inspection, shortage and long lead-time sourcing, and one-stop BOM procurement. Every part is verified before shipment.
FAQ
Is the EP4CE6 suitable for small designs?
Yes, the EP4CE6 is the entry-level Cyclone IV E density and is ideal for compact control and interface functions.
What tools configure the Cyclone IV E?
Intel Quartus Prime software supports the Cyclone IV E family for synthesis and programming.
