The Texas Instruments LM1117IMPX-ADJ/NOPB is an 800 mA low-dropout regulator with an adjustable output from 1.25 V to 13.8 V, set by two external resistors, in the industrial SOT-223 package. Its 1.2 V maximum dropout, ±1% reference accuracy and integrated current-limit and thermal-shutdown protection make it a flexible building block for custom voltage rails in industrial designs, supplied on tape and reel.
Key Specifications
| Manufacturer | Texas Instruments |
| Exact Manufacturer Part Number | LM1117IMPX-ADJ/NOPB |
| Product Category | Power Management – Voltage Regulators |
| Series / Family | LM1117 |
| Package / Case | SOT-223 |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C to +125°C |
| Power Supply | Up to 15 V input |
| Output Current | 800 mA |
| Output Voltage | Adjustable 1.25 V to 13.8 V |
| Dropout Voltage | 1.2 V max at 800 mA (1.1 V typical) |
| Output Accuracy | ±1% (fixed output) |
| Input Voltage | Up to 15 V |
| Adjustable Output | 1.25 V to 13.8 V |
| Protection | Current limit and thermal shutdown |
| Lifecycle Status | Active |
| Official Documentation | View official documentation |
Key Features
- 800 mA low-dropout linear regulator
- 1.2 V maximum dropout at full load
- Current-limit and thermal-shutdown protection
- Output tolerance ±1% for fixed versions
- Stable with 10 µF output capacitor
- Low quiescent current
Applications
- Adjustable point-of-load rails
- Custom supply voltages
- Industrial power management
- Prototyping and production
Sourcing
Availability, lead time, date code and commercial terms are subject to confirmation at the time of quotation.
Quality
CHIPER sources brand-new, unused components and provides quality inspection, shortage and long lead-time sourcing, and one-stop BOM procurement. Every part is verified before shipment.
FAQ
How is the output voltage set on the ADJ version?
It is set with an external resistor divider from 1.25 V to 13.8 V.
What is the reference accuracy of the ADJ version?
The internal reference is accurate to within about ±1%.
