24-Bit High Speed 8-/16-Channel ∆∑ ADCs with Selectable Speed/Resolution
Key Specifications
| Complete manufacturer part number | LTC2449CUHF#PBF |
|---|---|
| Manufacturer | Analog Devices |
| Description | 24-Bit High Speed 8-/16-Channel ∆∑ ADCs with Selectable Speed/Resolution |
| Package / case | 38-Lead QFN (5mm x 7mm w/ EP) |
| Product category | Analog-to-digital converters |
| Series / Family | LTC2449 |
| Power supply | 4.5 V to 5.5 V |
| Pins | 38 |
| Mounting Type | Surface Mount |
| Resolution | 24-bit |
| Channels | 8 differential / 16 single-ended |
| Sampling Rate | Up to 8 kHz (external osc.); 4 kHz mux rate |
| Interface | SPI-compatible serial |
| Input Type | Differential / single-ended |
| Reference | Differential external (GND to VCC) |
| Noise | 200 nVRMS at 13.8 Hz |
| INL | 0.0005% (no missing codes) |
| Supply Voltage | 4.5 V to 5.5 V |
| Operating temperature (manufacturer ordering record) | 0 °C to 70 °C |
| In stock | 2,280 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Manufacturer package outline drawing - not a product photo for 38-Lead QFN (5mm x 7mm w/ EP). Confirm electrical pin functions in the datasheet. Actual lot appearance and top marking require current-lot confirmation.
Request a Quote
Part of the ADI Precision ADC series.
