The Xilinx Spartan-6 XC6SLX4-2TQG144C is an entry-level 45 nm FPGA that provides 3,840 logic cells with 216 Kb of block RAM and 8 DSP48A1 slices in a 144-pin TQFP package. Running from a 1.2 V core supply at the commercial temperature range and -2 speed grade, it is a compact, cost-effective platform for simple glue logic, interfacing and small control functions in budget-conscious designs.
Key Specifications
| Manufacturer | Xilinx (AMD) |
| Manufacturer Part Number | XC6SLX4-2TQG144C |
| Product Category | FPGA – Field Programmable Gate Array |
| Package / Case | 144-TQFP (20 mm x 20 mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C to +85°C |
| Power Supply | Core (VCCINT) 1.2 V; I/O banks (VCCO) 1.2 V to 3.3 V |
| Logic Cells | 3,840 |
| Block RAM | 216 Kb |
| DSP48A1 Slices | 8 |
| User I/O | 102 |
| Speed Grade | -2 |
| Lifecycle Status | Active |
| Official Documentation | View official documentation |
Key Features
- 3,840 logic cells
- 216 Kb block RAM
- 8 DSP48A1 slices
- Low 1.2 V core power
- 144-pin TQFP for easy routing
- Commercial temperature range
- 45 nm process
- ISE / Vivado tool support
Applications
- Glue logic and interface bridging
- Simple control functions
- Consumer devices
- Display and I/O expansion
- Cost-sensitive designs
Sourcing
Availability, lead time, date code and commercial terms are subject to confirmation at the time of quotation.
Quality
CHIPER sources brand-new, unused components and provides quality inspection, shortage and long lead-time sourcing, and one-stop BOM procurement. Every part is verified before shipment.
FAQ
What logic resources does the XC6SLX4 provide?
The XC6SLX4 offers 3,840 logic cells with 216 Kb of block RAM and 8 DSP slices.
Does the TQFP package support hand assembly?
Yes, the 144-pin TQFP package provides a larger pitch than BGA options, easing prototyping and inspection.
