Manufacturer package outline drawing - not a product photo
3 MSPS, 12-Bit ADC in 8-Lead MSOP and 6-Lead TSOT
Key Specifications
| Complete manufacturer part number | AD7276AUJZ-REEL7 |
|---|---|
| Manufacturer | Analog Devices |
| Description | 3 MSPS, 12-Bit ADC in 8-Lead MSOP and 6-Lead TSOT |
| Package / case | 6-Lead TSOT |
| Product category | Analog-to-digital converters |
| Series / Family | AD7276 |
| Power supply | 2.35 V to 3.6 V |
| Pins | 6 |
| Mounting Type | Surface Mount |
| Resolution | 12-Bit |
| Channels | 1 (Single) |
| Sampling Rate | 3 MSPS |
| Interface | Serial SPI/QSPI/MICROWIRE/DSP |
| Reference | External (VDD-derived) |
| Input Type | Single-Ended |
| Supply Voltage | 2.35 V to 3.6 V |
| Power | 12.6 mW @ 3 MSPS |
| Operating temperature (manufacturer ordering record) | -40 °C to 125 °C |
| In stock | 4,053 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Manufacturer package outline drawing - not a product photo for 6-Lead TSOT. Confirm electrical pin functions in the datasheet. Actual lot appearance and top marking require current-lot confirmation.
Request a Quote
Part of the ADI Precision ADC series.
