Manufacturer package outline drawing - not a product photo
500 kSPS, 8-Channel, Software Selectable True bipolar Input, 12-Bit Plus Sign A/D Converter
Key Specifications
| Complete manufacturer part number | AD7327BRUZ-REEL7 |
|---|---|
| Manufacturer | Analog Devices |
| Description | 500 kSPS, 8-Channel, Software Selectable True bipolar Input, 12-Bit Plus Sign A/D Converter |
| Package / case | 20-Lead TSSOP |
| Product category | Analog to Digital Converters - ADC |
| Series / Family | AD7327 |
| Power supply | ±12 V analogue (VDD/VSS); 2.7 V to 5.25 V VCC |
| Pins | 20 |
| Mounting Type | Surface Mount |
| Resolution | 12-bit plus sign |
| Channels | 8 (software-selectable ranges) |
| Sampling Rate | 500 kSPS |
| Interface | SPI/QSPI/MICROWIRE/DSP-compatible serial |
| Reference | 2.5 V internal (external optional) |
| Input Type | True bipolar single-ended / differential / pseudo-differential |
| Input Range | ±10 V, ±5 V, ±2.5 V, or 0 V to +10 V |
| Power | 18 mW at max throughput |
| Operating temperature (manufacturer ordering record) | -40 °C to 85 °C |
| In stock | 5,928 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Manufacturer package outline drawing - not a product photo for 20-Lead TSSOP. Confirm electrical pin functions in the datasheet. Actual lot appearance and top marking require current-lot confirmation.
Request a Quote
Part of the ADI Precision ADC series.
