16-Bit, 8-Channel, 250 kSPS PulSAR ADC
Key Specifications
| Complete manufacturer part number | AD7689BCPZRL7 |
|---|---|
| Manufacturer | Analog Devices |
| Description | 16-Bit, 8-Channel, 250 kSPS PulSAR ADC |
| Package / case | 20-lead LFCSP (4mm x 4mm x 0.85mm w/EP) |
| Product category | Analog-to-digital converters |
| Series / Family | AD7689 |
| Power supply | 2.3 V to 5.5 V (VIO 1.8 V to 5.5 V) |
| Pins | 20 |
| Mounting Type | Surface Mount |
| Resolution | 16-bit (no missing codes) |
| Channels | 8 multiplexed |
| Sampling Rate | 250 kSPS |
| INL | ±1.5 LSB max (±0.4 LSB typ) |
| Interface | SPI/QSPI/MICROWIRE/DSP |
| Reference | Internal 2.5 V / 4.096 V or external |
| Input Type | Single-ended / differential / pseudo-bipolar |
| Supply Voltage | 2.3 V to 5.5 V |
| Operating temperature (manufacturer ordering record) | -40 °C to 85 °C |
| In stock | 11,342 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Manufacturer package outline drawing - not a product photo for 20-lead LFCSP (4mm x 4mm x 0.85mm w/EP). Confirm electrical pin functions in the datasheet. Actual lot appearance and top marking require current-lot confirmation.
Request a Quote
Part of the ADI Precision ADC series.
