Listing photo. Request current-lot confirmation.
16-Bit, 8-Channel, 500 kSPS PulSAR ADC
Key Specifications
| Complete manufacturer part number | AD7699BCPZ |
|---|---|
| Manufacturer | Analog Devices |
| Description | 16-Bit, 8-Channel, 500 kSPS PulSAR ADC |
| Package / case | 20-Lead LFCSP (4mm x 4mm w/ EP) |
| Product category | Analog-to-digital converters |
| Series / Family | AD7699 |
| Power supply | 2.3 V to 5.25 V |
| Pins | 20 |
| Mounting Type | Surface Mount |
| Resolution | 16-bit |
| Channels | 8 |
| Sampling Rate | 500 ksps |
| Interface | SPI / MICROWIRE / QSPI / DSP |
| Reference | Internal 4.096 V |
| Input | Unipolar 0 V to VREF |
| Operating temperature (manufacturer ordering record) | -40 °C to 85 °C |
| In stock | 2,466 pcs |
| Unit price | Request a quote |
| Lead time | To be confirmed |
Technical documentation and image source
The description is the manufacturer overview associated with this complete ordering code. Model-specific fields cite the ordering record or documentation. Confirm electrical test conditions, physical dimensions and certification scope in the linked original documents.
Request a Quote
Part of the ADI Precision ADC series.
